| Camera | Image Sensor | 1/4 type CMOS Sensor | |
| Effective Pixels | Approx. 1 megapixel | ||
| Scanning Mode | Progressive | ||
| Scanning Area | 3.89 mm (H) x 2.43 mm (V) {5/32 inches (H) x 3/32 inches (V)} | ||
| Minimum Illumination | Color: 0.9 lx (F2.8, Auto slow shutter: Off (1/30s), Gain:On(High)) Color: 0.06 lx (F2.8, Auto slow shutter: Max. 16/30s, Gain:On(High)) *1 BW: 0.6 lx (F2.8, Auto slow shutter: Off (1/30s), Gain:On(High)) BW: 0.04 lx (F2.8, Auto slow shutter: Off (16/30s), Gain:On(High)) *1 | ||
| White Balance | AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K) | ||
| Light Control Mode | Indoor scene (50 Hz / 60 Hz) / ELC | ||
| Shutter Speed | ELC (1/30 s), ELC (3/100 s), ELC (3/120 s), ELC (2/100 s), ELC (2/120 s), ELC (1/100 s), ELC (1/120 s), ELC (1/250 s), ELC (1/500 s), ELC (1/1,000 s), ELC (1/2,000 s), ELC (1/4,000 s), ELC (1/10,000 s) | ||
| Adaptive Black Stretch | ON / OFF | ||
| AGC | ON (HIGH) / ON (MID) / ON (LOW) / OFF | ||
| Electronic Sensitivity UP | OFF (1/30 s), Max. 2/30 s, Max. 4/30 s, Max. 6/30 s, Max. 10/30 s, Max. 16/30 s | ||
| Day Night (electrical) | OFF / AUTO | ||
| Digital Noise Reduction | HIGH / LOW | ||
| Video Motion Detection | ON / OFF (4 areas available) | ||
| Privacy Zone | ON / OFF (up to 2 zones available) | ||
| Camera Title (OSD) | Up to 20 characters (alphanumeric characters, marks) , On/Off | ||
| Lens | Focal Length | 3.6 mm | |
| Zoom Ratio | Extra zoom: 1.5x (at VGA resolution) | ||
| Angular Field of View | Horizontal: 57 °, Vertical: 34 ° | ||
| Maximum Aperture Ratio | 1 : 2.8 | ||
| Focusing Range | 0.4 m ~ ∞ | ||
| Wireless | Antena | 1x1 (Diversity) | |
| Transmission method | SISO (Single Input/ Single Output) -OFDM, OFDM,DSSS | ||
| Frequency range (center frequency) / Channel | BL-VP104WW: 2.412 GHz - 2.462 GHz (1 - 11ch) BL-VP104WWE: 2.412 GHz - 2.472 GHz (1 - 13ch) BL-VP104WWU: 2.412 GHz - 2.472 GHz (1 - 13ch) | ||
| Data transfer rate: *2 | IEEE802.11n: 6.5 - 72.2 Mbps IEEE802.11g: 6 - 54 Mbps IEEE802.11b: 1 - 11 Mbps | ||
| Access method | Infrastructure mode | ||
| Authentication method | Open System | ||
| Security: *3 | WPA/WPA2-PSK (TKIP/AES) WEP (64 bit/128 bit) | ||
| WPS | PBC method (push button method), PIN method (PIN code method) | ||
| Browser GUI | Camera Control | Brightness | |
| Display Mode | Spot, Quad: Image from 16 cameras can be displayed in 4 different Quad screens or 16 split screen (JPEG only). 20 characters camera title available. | ||
| Zoom | extra zoom(1x - 1.5x) and the electronic zoom (higher zoom factors, up to 6x). | ||
| Camera Title | Up to 20 alphanumeric characters | ||
| Clock Display | Time: 12H/24H, Date: 5 formats on the browser, Summer time (Manual) | ||
| Alarm Control | Reset | ||
| One Shot Capture | A still picture will be displayed on a newly opened window. | ||
| GUI/Setup Menu Language | English, Italian, French, German, Spanish, Russian, Chinese, Japanese | ||
| System Log | Up to 100 (Internal), error logs | ||
| Supported OS *4 *5 | Microsoft® Windows® 7, Microsoft® Windows Vista®,Microsoft® Windows® XP SP3 | ||
| Supported Browser | Windows® Internet Explorer® 9.0 (32 bit), Windows® Internet Explorer® 8.0 (32 bit), Windows® Internet Explorer® 7.0 (32 bit), Microsoft® Internet Explorer® 6.0 SP3 | ||
| Network | Network IF | 10Base-T / 100Base-TX, RJ-45 connector (female) | |
| Image Resolution *6 | Aspect ratio: [4 : 3] | H.264: SVGA(800 x 600) / VGA (640 x 480) / QVGA (320 x 240), up to 30 fps JPEG: SVGA(800 x 600)/ VGA (640 x 480) / QVGA (320 x 240), up to 30 fps | |
| Aspect ratio: [16 : 9] | H.264: 1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps JPEG: 1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps | ||
| H.264 | Transmission Mode | Constant bitrate / Frame rate / Best effort | |
| Frame Rate | 1 / 3 / 5 / 7.5 / 10 / 12 / 15 / 20 / 30 fps | ||
| Bit Rate/Client | 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 1,536 / 2,048 / 3,072 / 4,096 / 8,192 kbps | ||
| Image Quality | LOW / NORMAL / FINE | ||
| Refresh Interval | 1 fps ~ 30 fps | ||
| Transmission Type | UNICAST / MULTICAST | ||
| JPEG | Image Quality | 10 steps | |
| Refresh Interval | 0.1 fps ~ 30 fps | ||
| Transmission Type | PULL / PUSH | ||
| Supported Protocol | IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, RTP, FTP, SMTP, DNS, NTP, SNMP, DHCPv6, MLD, ICMP, ARP IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP,FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP | ||
| FTP Client | Alarm image transmission, FTP periodic transmission | ||
| No. of Simultaneous Users | Up to 14 users (Depends on network conditions) | ||
| Face Detection | ON / OFF (with XML notification) | ||
| Cellular Phone Compatibility | JPEG image | ||
| Mobile Terminal Compatibilty *7 | iPad, iPhone, iPod touch (iOS 4.2.1 or later) , AndroidTM mobile terminals | ||
| Alarm | Alarm Source | VMD, Command alarm | |
| Alarm Actions | E-mail notification, Indication on browser, FTP image transfer, Panasonic protocol output | ||
| Schedule | VMD | ||
| General | Safety/ EMC Standard | BL-VP104WW: UL60950-1 Ed.2, C22.2 NO.60950-1 Ed.2 FCC Part15 ClassB FCC Part15C BL-VP104WWE / BL-VP104WWU: IEC60950-1 Ed.2 EN55022 ClassB, EN55024 EN300 328 | |
| Power Source and Power Consumption | 6.5 V DC (Use only with Panasonic AC adapter) BL-VP104WW: max 3.5W (120 V AC/ 60 Hz) BL-VP104WWE: max. 3.5 W (230 V AC/ 50 Hz) BL-VP104WWU: max. 3.5 W (230 V AC/ 50 Hz) | ||
| Ambient Operating Temperature | 0 °C ~ 40 °C (32 °F ~ 104 °F) | ||
| Ambient Operating Humidity | Less than 90 % (no condensation) | ||
| Dimensions | 70 mm (W) x 70 mm (H) x 25.4 mm (D) {2-3/4 inches (W) x 2-3/4 inches (H) x 1 inch (D)} (excluding projection) | ||
| Mass (approx.) | Approx. 80 g {0.18 lbs} | ||
| Finish | Main body: ABS resin, white | ||
| Note | *1 Converted value *2 The actual line speed may be different depending on the network environment and the wireless devices connected. *3 Depending on the wireless router (wireless access point) used, connections may not possible between the camera and the wireless router. When connecting with 802.11n, select WPA-PSK (AES) or WPA2-PSK (AES) for security. *4 Refer to "Notes on Windows Vista® / Windows® 7" on the provided CD-ROM for further information about system requirements for a PC and precautions when using Microsoft® Windows® 7 or Microsoft® Windows Vista®. *5 When using IPv6 for communication, use Microsoft® Windows® 7 or Microsoft® Windows Vista®. *6 Transmission for 2 streams can be individually set in the same compression method. *7 For further information about compatible devices, refer to our website (http://panasonic.net/pss/security/support/info.html). |
||
