| Camera | Image Sensor | 1/2.8 type MOS Sensor | |
| Effective Pixels | Approx. 2.4 megapixel | ||
| Scanning Mode | Progressive Scan | ||
| Scanning Area | 5.44 mm (H) x 3.43 mm (V) {3/16 inches (H) × 1/8 inches (V)} | ||
| Minimum Illumination | Color: 0.5 lx, BW: 0.06 lx (F1.6, Auto slow shutter: Off (1/30s), Gain:On(High)) Color: 0.03 lx, BW 0.004 lx (F1.6, Auto slow shutter: Max. 16/30s, Gain:On(High)) *¹ |
||
| White Balance | AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K) | ||
| Light Control Mode | Outdoor scene: Automatic integration of ALC and ELC Indoor scene [50 Hz]: Automatic integration of ALC and ELC (up to 1/100 s) Indoor scene [60 Hz]: Automatic integration of ALC and ELC (up to 1/120 s) Fix shutter |
||
| Shutter Speed | Fix shutter: 1/30, 3/100, 3/120, 2/100, 2/120, 1/100, 1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000 (only at Super Dynamic Off) | ||
| Super Dynamic | ON / OFF | ||
| Face Super Dynamic | ON / OFF (Only at Super Dynamic: ON) | ||
| Adaptive Black Stretch | ON / OFF (Only at Super Dynamic: OFF) | ||
| Fog Compensation | ON / OFF | ||
| AGC | ON (LOW, MID, HIGH) / OFF | ||
| Electronic Sensitivity UP | OFF / AUTO (Max. 2x (2/30 s), 4x (4/30 s), 6x (6/30 s), 10x (10/30 s), 16x (16/30 s)) | ||
| Day & Night (IR) | Mode: AUTO1 / AUTO2 / AUTO3 / ON / OFF, Level:High / Low, with external control | ||
| Digital Noise Reduction | High / Low | ||
| Video Motion Detection | 4 areas, Sensitivity: 15 steps, Detection size: 10 steps | ||
| Privacy Zone | Up to 8 zones / Up to 32 zones, Gray / Mosaic | ||
| VIQS | Up to 2 zones at preset position 1-8 and except preset | ||
| Camera Title (OSD) | Up to 20 characters (alphanumeric characters, marks) | ||
| Focus Distance | Limited / Unlimited | ||
| Lens | Focal Length | 4.3 mm ~129.0 mm, 30x | |
| Zoom Ratio | 30x / 90x with extra optical zoom (at 640x360) | ||
| Digital (Electrical) Zoom | 12x (Max. 1080x combined with extra optical zoom at 640x360) | ||
| Angular Field of View | H: 2.6° (TELE) ~ 64.6° (WIDE) V: 1.6° (TELE) ~ 38.2° (WIDE) |
||
| Maximum Aperture Ratio | 1 : 1.6 (WIDE) ~ 4.7 (TELE) | ||
| Focusing Range | 2.0 m ~ ∞ | ||
| Aperture Range | F1.6 ~ Close | ||
| Pan and Tilt | Panning Range | 360° endless | |
| Panning Speed | Manual: approx. 0.065°/s ~ 120°/s, Up to 256 steps (depending on the controller) Preset: up to approx. 300°/s |
||
| Tilting Range | –25° ~ 205° (upward-level-downward) Selectable tilting angle : 0° / -5° / -10° / -15° / -20° / -25° |
||
| Tilting Speed | Manual: approx. 0.065°/s ~ 120°/s, Up to 256 steps (depending on the controller) Preset: up to approx. 300°/s |
||
| Proportional Pan / Tilt Control | Yes | ||
| Number of Preset Positions | 256 | ||
| Auto Mode | Preset Sequence / Auto Pan / Auto Track / Patrol | ||
| Image Hold | ON / OFF | ||
| PTZ Position Display | ON / OFF | ||
| Self Return | 10 s / 20 s / 30 s / 1 min / 2 min / 3 min / 5 min / 10 min / 20 min / 30 min / 60 min | ||
| Map Shot | 360? Map Shot / Preset Map Shot | ||
| Browser GUI | Camera Control | Pan/Tilt (256 Steps), Zoom, Focus, Click Centering, Drag Zoom, Iris, Preset Position Call and Programme, Auto Mode | |
| Display Mode | Spot, Quad: Image from 16 cameras can be displayed in 4 different Quad screens or 16 split screen (JPEG only). 20 characters camera title available. | ||
| Camera Title | Up to 20 alphanumeric characters | ||
| Clock Display | Time: 12H/24H, Date: 5 formats on the browser, Summer time (Manual) | ||
| Alarm Control | Reset | ||
| One Shot Capture | A still picture will be displayed on a newly opened window. | ||
| Audio | Mic (Line) Input: ON / OFF Volume adjustment: Low / Middle / High, Audio Output: ON / OFF Volume adjustment: Low / Middle / High | ||
| SD Memory Data Download | Still or Motion Images recorded in the SDXC / SDHC / SD Memory Card can be downloaded | ||
| GUI/Setup Menu Language | English / Italian / French / German / Spanish / Russian / Chinese / Japanese | ||
| System Log | Up to 100 (Internal) Up to 4,000 (SDXC / SDHC / SD Memory when the Recording Format is set to JPEG) Error Logs |
||
| Supported OS *² *³ | Microsoft® Windows® 8, Microsoft® Windows® 7, Microsoft® Windows Vista®, Microsoft® Windows® XP SP3 |
||
| Supported Browser | Windows® Internet Explorer® 10.0 (32 bit), Windows® Internet Explorer® 9.0 (32 bit), Windows® Internet Explorer® 8.0 (32 bit),Windows® Internet Explorer® 7.0 (32 bit) |
||
| Network | Network IF | 10Base-T / 100Base-TX, RJ-45 connector | |
| Image Resolution | Image Capture Mode:2 mega pixel [16:9] | H.264 :1,920 x 1,080 / 640 x 360 / 320 x 180, up to 30 fps JPEG (MJPEG):1,920 x 1,080 / 640 x 360 / 320 x 180, up to 30 fps |
|
| Image Capture Mode:1.3 mega pixel [16:9] | H.264 :1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps JPEG (MJPEG):1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps |
||
| Image Capture Mode:1.3 mega pixel [4:3] | H.264 :1,280 x 960 / VGA(640 x 480) / QVGA(320 x 240), up to 30 fps JPEG (MJPEG):1,280 x 960 / VGA(640 x 480) / QVGA(320 x 240), up to 30 fps |
||
| H.264 *? | Transmission Mode | Constant bitrate / Frame rate priority / Best effort /Advanced VBR | |
| Frame Rate | 1 / 3 / 5 / 7.5 / 10 / 12 / 15 / 20 / 30 fps | ||
| Bit Rate/Client | 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 1,536 / 2,048 / 3,072 / 4,096 / 6,144 / 8,192 / 10,240 / 12,288 / 14,336 kbps | ||
| Image Quality | LOW / NORMAL / FINE | ||
| Refresh Interval | 0.2 / 0.25 / 0.33 / 0.5 / 1 / 2 / 3 / 4 / 5 s | ||
| Transmission Type | UNICAST / MULTICAST | ||
| JPEG | Image Quality | 10 steps | |
| Refresh Interval | 0.1 fps ~ 30 fps | ||
| Transmission Type | PULL / PUSH | ||
| Audio Compression | G.726 (ADPCM) 32 kbps / 16 kbps, G.711 64 kbps for transmitting, AAC for audio recording and sound detection | ||
| Audio Mode | OFF / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) | ||
| Authentication for Audio | Level 1 only / Level 2 higher / All users | ||
| Total Bit Rate | 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 2,048 / 4,096 / 8,192 kbps / Unlimited | ||
| Supported Protocol | IPv6:TCP/IP, UDP/IP, HTTP, HTTPS, RTP, FTP, SMTP, DNS, NTP, SNMP, DHCPv6 , ICMP, ARP IPv4:TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP,FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP , IGMP , ICMP , ARP |
||
| FTP Client | Alarm image transmission, FTP periodic transmission (When the FTP transmission is failed, backup on an optional SDXC/SDHC/SD memory card is available. ) | ||
| No. of Simultaneous Users | Up to 14 users (Depends on network conditions) | ||
| SDXC/SDHC/SD Memory Card (Option) | H.264 recording (Audio recording is enable):Manual REC / Alarm REC (Pre/Post) / Schedule REC JPEG recording:Manual REC / Alarm REC (Pre/Post) / Backup upon network failure Compatible SD (SDHC/SDXC) card: Panasonic 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64GB** model *SDHC card, ** SDXC card (except miniSD card and microSD card) |
||
| Cellular Phone Compatibility | JPEG image | ||
| Mobile Terminal Compatibility | iPad, iPhone, iPod touch | ||
| Alarm | Alarm Source | 3 terminals input, VMD, Command alarm, Sound detection | |
| Alarm Actions | SDXC/SDHC/SD memory recording, E-mail notification, Indication on browser, FTP image transfer, Panasonic protocol output |
||
| Alarm Log | With SDXC / SDHC / SD memory card: 5,000 logs, without SDXC / SDHC / SD memory card: 1,000 logs |
||
| Schedule | Alarm / VMD / Access permission / H.264 recording / Sound detection | ||
| Input/Output | Monitor Output(for adjustment) | VBS : 1.0V[p-p] / 75Ω , NTSC / PAL composite,∅3.5 mm monaural mini jack |
|
| Microphone/Line Input | MIC IN and Line IN are selectable. ∅3.5 mm stereo mini jack (monaural input) (Applicable microphone: Plug-in power type) Supply voltage: 2.5 V ±0.5 V Input impedance: approx. 2 kΩ | ||
| Audio Output | ∅3.5 mm stereo mini jack (monaural output) Line level | ||
| External I/O Terminals | ALARM IN 1 / DAY/NIGHT IN, ALARM IN 2 / ALARM OUT, ALARM IN 3 / AUX OUT | ||
| General | Safety/EMC Standard | UL (UL60950-1), C-UL (CAN/CSA C22.2 No.60950-1), CE, IEC60950-1 FCC Part15 Class A, ICES-003 Class A, EN55022 Class B, EN55024 |
|
| Power Source and Power Consumption | 12 V DC : 1.0 A PoE: 12 W (IEEE802.3af compliant, Class 0 device) |
||
| Ambient Operating Temperature | PoE : -10°C ~ +55°C (14 °F ~ 131 °F) | ||
| Ambient Operating Humidity | Less than 90 % (no condensation) | ||
| Water and Dust Resistance | IP66, IEC60529 measuring standard compatible | ||
| Dimensions | ∅144 mm x 208 mm(H) {∅5-11/16 inches x 8-3/16 inches(H)} | ||
| Mass (approx.) | Approx. 1.3 kg (2.87 lbs) | ||
| Finish | Main body : ABS resin, sail white | ||
| NOTE | *1 Converted value *2 Refer to "Notes on Windows Vista® / Windows® 7 / Windows® 8" on the provided CD-ROM for further information about system requirements for a PC and precautions when using Microsoft® Windows® 8 or Microsoft® Windows® 7 or Microsoft® Windows Vista®. *3 When using IPv6 for communication, use Microsoft® Windows® 8 or Microsoft® Windows® 7 or Microsoft® Windows Vista®. *4 Transmission for 2 streams can be individually set in the same compression method. |
||
