| Camera | Image Sensor | 1/3 type MOS Sensor | |
| Effective Pixels | Approx. 1.3 megapixel | ||
| Scanning Mode | Progressive scan | ||
| Scanning Area | 4.8 mm (H) x 3.6 mm (V) | ||
| Minimum Illumination | Color: 0.8 lx, B/W: 0.4 lx at F2.2 (Shutter: 1/30 s, AGC: High), Color: 0.05 lx, B/W: 0.03 lx at F2.2 (Shutter: 16/30 s, AGC: High) |
||
| White Balance | AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K) | ||
| Light Control Mode | ELC (maximum exposure time): | 1/30, 3/100, 3/120, 2/100, 2/120, 1/100, 1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000 | |
| Adaptive Black Stretch | ON / OFF | ||
| AGC | ON (LOW, MID, HIGH ) / OFF | ||
| Electronic Sensitivity UP | OFF, max. 2/30 s, max. 4/30 s, max. 6/30 s, max. 10/30 s, max. 16/30 s | ||
| Simple Day/Night Mode | AUTO / OFF | ||
| Digital Noise Reduction | High / Low | ||
| Video Motion Detection | 4 areas, Sensitivity: 15 steps, Detection size: 10 steps | ||
| Privacy Zone | Up to 2 zones, Gray | ||
| VIQS | ON / OFF | ||
| Camera Title (OSD) | Up to 20 alphanumeric characters | ||
| Lens | Zoom Ratio | 2x with extra zoom (at VGA) | |
| Digital (Electronic) Zoom | 4x (Max. 8x combined with extra zoom at VGA | ||
| Focal Length | 3.54 mm | ||
| Maximum Aperture Ratio | 1 : 2.2 | ||
| Focusing Range | 0.5 m ~ ∞ | ||
| Angular Field of View | H: 70.3°, V: 55.4° | ||
| Browser GUI | Display Mode | Spot, Quad: Image from 16 cameras can be displayed in 4 different Quad screens or 16 split screen (JPEG only). 20 characters camera title available. | |
| Camera Title | Up to 20 alphanumeric characters | ||
| Clock Display | Time: 12H / 24H, Date: 5 formats on the browser, Summer time (Auto / Manual) | ||
| One Shot Capture | A still picture will be displayed on a newly opened window | ||
| GUI/Setup Menu Language | English, Italian, French, German, Spanish, Russian, Chinese, Japanese | ||
| System Log | Up to 100 (Internal) | ||
| Supported OS | Microsoft® Windows® 7 Professional 64 bit/32 bit, Microsoft® Windows Vista® Business SP1 32 bit, Microsoft® Windows® XP Professional SP3 The language of the OS must be same as selected GUI language. |
||
| Supported Browser | Windows® Internet Explorer® 9.0 (32 bit), Windows® Internet Explorer® 8.0 (32 bit), Windows® Internet Explorer® 7.0 (32 bit), Microsoft® Internet Explorer® 6.0 SP3 | ||
| Network | Network IF | 10Base-T / 100Base-TX, RJ-45 connector | |
| Image Resolution*1 | Aspect ratio: [4 : 3] | H.264: 1,280 × 960 / VGA (640 × 480) / QVGA (320 × 240), up to 30 fps JPEG (MJPEG): 1,280 × 960 / VGA (640 × 480) / QVGA (320 × 240), up to 30 fps | |
| Aspect ratio: [16 : 9] | H.264: 1,280 × 720 / 640 × 360 / 320 × 180, up to 30 fps JPEG (MJPEG): 1,280 × 720 / 640 × 360 / 320 × 180, up to 30 fps | ||
| H.264 | Transmission Priority | Constant bitrate / Framerate/ Best effort | |
| Frame Rate | 1 / 3 / 5 / 7.5 / 10 / 12 / 15 / 20 / 30 fps | ||
| Bit Rate/Client | 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 1,536 / 2,048 / 3,072 / 4,096 / 8,192* kbps / Unlimited * Only for WV-SP105 |
||
| Image Quality | LOW / NORMAL / FINE | ||
| Refresh Interva | 0.2 s / 0.25s / 0.33 s / 0.5 s / 1 s / 2 s / 3 s / 4 s / 5 s | ||
| Transmission Type | UNICAST / MULTICAST | ||
| JPEG (MJPEG) | Image Quality | 0 SUPER FINE / 1 FINE / 2 / 3 / 4 / 5 NORMAL / 6 / 7 / 8 / 9 LOW (10 steps: 0~9) | |
| Transmission Type | PULL / PUSH | ||
| Total Bit Rate | 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 2,048 / 4,096 / 8,192 kbps / Unlimited | ||
| Supported Protocol | IPv6: TCP/IP, UDP/IP, HTTP, RTP, FTP, SMTP, DNS, NTP, SNMP, DHCPv6,ICMPv6 IPv4: TCP/IP, UDP/IP, HTTP, RTSP, RTP, RTP/RTCP, FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP,IGMP,ICMP,ARP |
||
| FTP Client | Alarm image transfer, Periodic image transfer | ||
| No. of Simultaneous Users | Up to 14 users (Depends on network conditions) | ||
| Face Detection | ON / OFF (with XML noti?cation) | ||
| Cellular Phone Compatibility | JPEG image | ||
| Mobile Terminal Compatibility *2 | iPad, iPhone, iPod touch (iOS 4.2.1 or later) , AndroidTM mobile terminals | ||
| Alarm | Alarm Source | VMD, Command alarm | |
| Alarm Actions | E-mail noti?cation, Indication on browser, FTP image transfer, Panasonic protocol output | ||
| Schedule | VMD/Access permission | ||
| General | Safety/EMC Standard | NTSC | UL (UL60950), FCC (Part15 ClassA), C-UL (CAN/CSA C22.2 No.60950), DOC (ICES003 ClassA) |
| PAL | CE (EN60950, EN55022 ClassB, EN55024), GOST (GOST R 51558) | ||
| Power Source/Consumption | 12 V DC: approx. 200 mA PoE: approx. 2.8 W (IEEE802.3af compliant, Class 2 device) |
||
| Ambient Operating Temperature/Humidity | 0 °C ~ +40 °C (32 °F ~ 104 °F), 90 % or less (without condensation) | ||
| Dimensions | 55 mm (W) x 55 mm (H) x 122 mm (D) (2-5/32" (W) x 2-5/32" (H) x 4-13/16" (D)) (excluding connectors/terminals) | ||
| Mass (approx.) | 180 g (0.40 lbs.) | ||
| NOTE | *1 [4 : 3] and [16 : 9] are alternative. *2 For further information about compatible devices, refer to our website (http://panasonic.net/pss/security/support/info.html). |
||
