H.264+ & H.264 dual-stream encoding
25/30fps@2M(1920×1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8 mm fixed lens (3.6mm optional)
Max IR LEDs Length 30m
IP67, PoE
escription
| Camera | Image Sensor | 1/2.9” 2Megapixel progresive CMOS | ||||
| Effective Pixels | 1920(H) x1080(V) | |||||
| RAM/ROM | 256MB/16MB | |||||
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s | |||||
| Minimum Illumination | 0.1Lux/F2.0(Color), 0Lux/F2.0(IR on) | |||||
| S/N Ratio | More than 50dB | |||||
| IR Distance | Distance up to 30m(98ft) | |||||
| IR On/Off Control | Auto/ Manual | |||||
| IR LEDs | 18 | |||||
| Focal Length | 2.8 mm (3.6 mm optional) | |||||
| Max. Aperture | F2.0/F2.0 | |||||
| Angle of View | H:110°/83°,V:57°/44° | |||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify | |
| 2.8 mm | 45m(147ft) | 18m(59ft) | 9m(30ft) | 5m(16ft) | ||
| 3.6 mm | 57m(187ft) | 23m(75ft) | 11m(33ft) | 6m(20ft) | ||
| PTZ | Pan/Tilt Range | Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360° | ||||
| Video | Compression | H.264+/H.264 | ||||
| Streaming Capability | 2 Streams | |||||
| Resolution | 1080P(1920x1080)/720P(1280×720)/ D1(704×576/704×480)/CIF(352×288/352×240) | |||||
| Frame Rate | 2M (1 ~ 25/30fps) | |||||
| D1/CIF(1 ~ 25/30fps) | ||||||
| Bit Rate | H264:24K ~ 8192Kbps | |||||
| Noise Reduction | 3D DNR | |||||
| Electronic Image | Support | |||||
| Smart IR | Support | |||||
| Digital Zoom | 16x | |||||
| Flip | 0°/90°/180°/270° | |||||
| Network | Ethernet | RJ-45 (10/100Base-T) | ||||
| Protocol | HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; | |||||
| DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; | ||||||
| Bonjour;802.1x;Multicast;ICMP;IGMP; | ||||||
| Certifications | Certifications | CE (EN 60950:2000) | ||||
| UL:UL60950-1 | ||||||
| FCC: FCC Part 15 Subpart B | ||||||
| Electrical | Power Supply | DC12V PoE (802.3af)(Class 0) | ||||
| Power Consumption | <5.4W | |||||
| Environmental | Operating Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | ||||
| Strorage Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | |||||
| Ingress Protection | IP67 | |||||
| Construction | Casing | Metal+Plastic | ||||
| Dimensions | Φ108mm×84.9mm(4.25'x3.15') | |||||
| Net Weight | 0.23Kg(0.51lb) | |||||
| Gross Weight | 0.387Kg(0.85lb) | |||||
