| General | ||
|---|---|---|
| Operating Conditions: | -40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
|
| Power Supply: | 12 V DC±10% | |
| Power Consumption: | Max. 1.8 W (Max. 4 W with IR cut filter on) |
|
| IR Range: | Approx 10 to 20 meters | |
| Dimension: | Φ89.5 × 69.8 mm (3.52” × 2.75”) | |
| Weight: | 200 g (0.44 lbs) | |
| Camera | ||
|---|---|---|
| Image Sensor: | 1/3” DIS | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 976(H)×496(V) | |
| Min. Illumination: | 0.1 Lux @ (F1.2,AGC ON),0 Lux with IR | |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens: | 3.6 mm (2.8mm,6mm optional) Angle of view: 68.4° (3.6 mm) |
|
| Lens Mount: | M12 | |
| Adjustment Range: | Pan: 0 - 355°, Tilt: 0 - 85°, Rotation: 0 - 360° | |
| Day& Night: | IR cut filter with auto switch | |
| Horizontal Resolution: | 700 TVL | |
| Synchronization: | Internal Synchronization | |
| Video Output: | 1Vp-p Composite Output (75Ω/BNC) | |
| S/N Ratio: | More than 62 dB | |
