Embedded processor
H.264 video compression
Support HDCVI/ AHD/TVI/CVBS/IP video inputs
Max 5/10/18 channels IP camera inputs
Long transmission distance over coax cable
Support 1 SATA HDD, up to 6TB
Description
| System | Main Processor | Embedded Processor |
| Operating System | Embedded LINUX | |
| Display | Interface | 1 HDMI ,1 VGA |
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 | |
| Multi-screen Display | 4CH: 1/4/6 | |
| 8CH: 1/4/8/9/16 | ||
| 16CH: 1/4/8/9/16/25 | ||
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
| Video Detection and Alarm | Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering | |
| Alarm input | N/A | |
| Relay Output | N/A | |
| Tracking Trigger Event | N/A | |
| Playback and Backup | Playback | 4CH: 1/4 |
| 8CH: 1/4/9 | ||
| 16CH: 1/4/9/16 | ||
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) | |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom | |
| Backup Mode | USB Device/Network | |
| Storage | Internal HDD | 1 SATA Port, up to 6TB capacity |
| HDD Mode | Single | |
| eSATA | N/A | |
| Auxiliary Interface | Front Cover | N/A |
| USB | 2 USB Ports (2 USB 2.0) | |
| RS232 | N/A | |
| RS485 | 1 Port, for PTZ Control | |
| Third-party Support | Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Audio and Video | HDCVI Camera Input | 4/8/16 Channel |
| IP Camera Input | 4+1: each channel up to 2MP | |
| 8+2/16+2:each channel up to 5MP | ||
| Audio In/Out | 1-Jan | |
| Two-way Talk | Reuse audio in/out, RCA | |
| Recording | Compression | H.264 |
| Resolution | 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF | |
| Record Rate | Main Stream: | |
| 4CH:1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps) | ||
| 8/16CH:1080N(12fps)/720P(15fps)/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps) | ||
| Sub steram:D1/CIF/QCIF(1~25/30fps) | ||
| Bit Rate | 1Kbps ~ 6144Kbps Per Channel | |
| Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop | |
| Record Interval | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec | |
| Network | Interface | 1 RJ-45 Port (100M) |
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server,P2P, IP Search (Support Dahua IP camera, DVR, NVS, etc.) | |
| Max. User Access | 128 users | |
| Smart Phone | iPhone, iPad, Android | |
| Interoperability | ONVIF 2.4.1, CGI Conformant | |
| Electrical | Power Supply | DC12V/2A |
| Power Consumption | ||
| Environmental | Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Storage Conditions | -40°C ~ +60°C (-40°F ~ +140°F)/Less than 90% RH | |
| Construction | Dimensions | Compact 1U, 260×236×48mm(10.2"×9.3"×1.9") |
| Net Weight | 0.75kg ( 1.7lb) (without HDD) |
