| Lentes | ||
|---|---|---|
| Focal Length: | 4-92mm, 23x | |
| Zoom Speed: | Approx.3.0s(Optical Wide-Tele) | |
| Angle of View: | 49-2.2 degree(Wide-Tele) | |
| Minimum Working Distance: | 10-1000mm (Wide-Tele) | |
| Aperture Range: | F1.4-F3.5 | |
| Pan & Tilt | ||
|---|---|---|
| Pan Range: | 360°endless | |
| Pan Speed: | Pan Manual Speed: 0.1°-250°/s,; Pan Preset Speed: 300°/s | |
| Tilt Range: | -5°~90° (Auto Flip ) | |
| Tilt Speed: | Tilt Manual Speed: 0.1°-150°/s,; Tilt Preset Speed: 200°/s | |
| Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples | |
| Number of Preset: | 256 | |
| Patrol: | 8 patrols, up to 32 presets per patrol | |
| Pattern: | 4 patterns, with the total recording time not less than 10 minutes | |
| Power loss recovery: | Support | |
| Park Action: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan | |
| PTZ Position Display: | ON/OFF | |
| Freeze Frame: | Support | |
| Entrada & Saída | ||
|---|---|---|
| Turbo HD Output: | 1 turbo HD720p output, BNC | |
| Configurações Gerais | ||
|---|---|---|
| RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive | |
| Menu Language: | English / Chinese | |
| Power Supply: | 24V AC | |
| Power Consumption: | Outdoor dome: Max. 20W (Heater On), Max. 12W(Heater Off); Indoor dome: Max.12W | |
| Working Temperature/Humidity: | -30 °C-65°C(-22°F-149°F)(outdoor dome) / -10°C-50°C(14°F-122°F)(indoor dome ) 90% or less |
|
| Protection Level: | IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection |
|
| Dimensions: | φ220×305mm (φ8.66”×12.00”)(Outdoor) φ183.4×243mm(φ7.22”×9.56”) (Indoor) φ245×236mm(φ9.65”×9.29”) (In-ceiling) |
|
| Weight (approx.): | 3Kg (6.61 Ibs) | |
| Mount Option: | Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJpole; Power box mount:DS-1602ZJ-box;Swan-neck mount: DS-1619ZJ |
|
| Camera | ||
|---|---|---|
| Image Sensor: | 1/3" Progressive Scan CMOS | |
| Effective Pixels: | 1280(H)x720(V) | |
| Sistema de sinal: | PAL/NTSC | |
| Minimum Illumination: | Color: 0.05Lux@(F1.4,AGC ON) B/W: 0.005Lux@(F1.4,AGC ON) |
|
| Balanço de branco: | Auto / Manual / ATW / Indoor / Outdoor | |
| AGC: | Auto/Manual | |
| BLC: | ON/OFF | |
| WDR: | Support | |
| Tempo do obturador: | PAL: 1-1/10,000s NTSC: 1-1/10,000s |
|
| Dia e noite: | ICR | |
| Digital Zoom: | 16x | |
| Privacy Masking: | 8 privacy masks programmable | |
| Auto Focus: | Auto / Semi-automatic / Manual | |
