Features
| Specification | |
|---|---|
| Pickup Device | 1/4" 1.0Mega pixel Color CMOS (OV9712) |
| Resolution | AHD 720P / CVBS 800 TVL |
| System | PAL/NTSC |
| Effective Pixels | 1280(H)×720(V) 1.0M Pixels |
| Min.illumination | Color:1.0Lux(F1.2,50IRE,AGC ON),Black and White:0.1Lux(F1.2,50IRE,AGC ON) |
| Electronic Shutter | PAL ?1/50 ? 1/100,000s NTSC?1/60 ? 1/100,000s |
| WDR | Digital WDR |
| Frame accumulation | 0-30X |
| 2D-DNR | Off / Low / Middle / High |
| Image Freeze | Support |
| BLC/HLC | Support |
| Anti-fog | 0-2 grade |
| S/N Ratio | >60dB (AGC Off ) |
| White Balance | Auto White Balance |
| Day & Night | ICR switch |
| Mirroring | Horizontal mirror / vertical mirror |
| Privacy Mask | Support |
| Language | Chinese / English / German / French / Italian / Spanish / Portuguese / Russian / Dutch / Turkish / Poland |
| Video Output | 1.0Vp-p composite output, 75Ω |
| Power Supply | DC12V ±10% |
| Infrared Lamp | 24xφ5/850nm |
| IR Distance | 10-15m |
| Power Consumption | 30mA/150mA?IR ON? |
| Lens | 3.6/6mm Fixed M12 Lens |
| Size | φ94*80mm |
| Weight | 0.18KG |
| Operating Temp. | -20? ~ 60? |
| Humidity | Relative humidity below 90% |
